Counterbalanced mobile crane FLEX G750DBR Product Details

FLEX-G750-DBR-mini-gru-elettrica-con-radiocomando
FLEX-G750-DBR-mini-gru-elettrica-contrappesata
FLEX-G750-DBR-gru-portatile-elettrica
FLEX-G750-DBR-mini-gru-con-doppio-sfilo-elettrico
FLEX-G750-DBR-gru-elettrica-contrappesata
FLEX-G750-DBR-gru-elettrica-con-contrappesi
FLEX-G750-DBR-soluzione-di-sollevamento-elettrico

FLEX G750DBR MOBILE LIFTING SWIVEL CRANE

WITH REMOTE CONTROL LIFTING CAPACITY 750 KG

MAXIMUM CAPACITY

750 kg

Max Overhang

2400 mm

COLUMN

Swivel 270°

MAX HEIGHT

3938 mm

The FLEX G750DBR lifting equipment is a battery powered counterbalanced swivel crane that allows lifting loads of up to 750 kg.

Thanks to the double telescopic extension it guarantees a free reach of 2.4 metres.

The rotation of the slewing ring, which can be locked every 30°, is done manually and is facilitated by the presence of bearings and two ergonomic handles located on the upper part of the ballast. Equipped with 2 fixed wheels and a wheel motor connected directly to the tiller for maximum manoeuvrability in tight spaces.

Standard features: maintenance-free sealed AGM batteries, external battery charger, LED stack tower lights indicating correct crane operation and overload warning, emergency stop.

The Flex G750DBR counterbalanced mobile crane also has a multifunctional display showing charge level, battery voltage and hours of operation.

Lift, lower, extend and retract of the boom are electric controlled. All movements are adjustable by the operator through a wireless remote control. Speed ​​and proportionality are managed via the potentiometer on the remote control.

It is a universal mobile crane with unlimited application possibilities. With the FLEX G750DBR mini crane, thanks to its 270° rotation and telescopic boom, components such as moulds, spare parts, semi-finished products and other loads can be placed on CNC machining centers, racks, assembly benches and any hard-to-access location.

Safety features :

Dynamic load limiter that prevents overloading and potential accidents. It continuously monitors the load being lifted or handled and automatically limits the operation if the load exceeds the predetermined safe limit.

A block valve is activated automatically in the event of a hydraulic hose rupture, preventing uncontrolled load descent.



The tiller handle is equipped with a speed selector that allows the speed of the vehicle to be adapted to different operating requirements. Two positions are available:

  • Slow mode: Limits the maximum speed to 1.5 km/h, ideal for precise manoeuvring in confined spaces and gentle handling of loads.
  • Standard speed: Allows a maximum speed of 3 km/h, suitable for travelling long distances in standard conditions

The FLEX G750DBR counterbalanced crane allows loads to be handled and lifted in full compliance with current regulations for the protection of operator safety.

AVAILABLE UPON REQUEST

FIND OUT MORE

PRODUCT GALLERY

FLEX-G750DBR-sistema-mobile-per-sollevamento-carichi-fino-a-750-kg
Gru-motorizzata-con-braccio-girevole-750-kg-mod.-Flex-G750DBR-rotated
veicolo-elettrico-con-braccio-sollevatore-Flex-G750DBR

Traction

Electric. Slow/fast speed

MAX HEIGHT

3938

COLUMN

Swivel 270°

LIFTING

Electric with adjustable and proportional speed

MAIN FEATURES

MAXIMUM CAPACITY (Kg)

750

Front Dimension (mm)

990

Max Overhang

2400

Lowering

Electric with adjustable and proportional speed

Boom

Electric with adjustable and proportional speed

POPULAR APPLICATIONS & MARKET SEGMENTS

MAINTENANCE

Cantilever cranes are often used in the aviation industry for specific aircraft-related tasks. For handling engines, dismantling seats, raising sensitive components such as radars or antennas, etc.

TESTING

Counterbalance cranes are versatile and precise tools for positioning components on test benches. They offer benefits in safety, productivity and flexibility, making them a common choice for companies involved in product manufacturing and testing.

CNC MACHINES

Using mini mobile cranes for tool changing and positioning on CNC machines improves the efficiency, safety and precision of machining operations. They have become essential equipment in many high-precision production workshops.

ASSEMBLY LINE

Using mini mobile cranes along assembly lines can improve production efficiency, reduce the risk of accidents, and enable loads to be handled precisely in spaces where other equipment can't be maneuvered. This helps optimize manufacturing operations.

PICKING

Using mini mobile cranes to bypass ground obstacles, where traditional workshop cranes cannot access due to their stabilizing legs, offers a practical and effective solution in various scenarios. They are extremely useful tools for lifting tasks in hard-to-reach spaces.

PLASTIC INJECTION PROCESSES

Using counterbalance cranes to change molds is a common practice in the manufacturing industry, especially in the production of plastic parts, die-cast products and other molding processes.

Description

The FLEX G750DBR lifting equipment is a battery powered counterbalanced swivel crane that allows lifting loads of up to 750 kg.

Thanks to the double telescopic extension it guarantees a free reach of 2.4 metres.

The rotation of the slewing ring, which can be locked every 30°, is done manually and is facilitated by the presence of bearings and two ergonomic handles located on the upper part of the ballast. Equipped with 2 fixed wheels and a wheel motor connected directly to the tiller for maximum manoeuvrability in tight spaces.

Standard features: maintenance-free sealed AGM batteries, external battery charger, LED stack tower lights indicating correct crane operation and overload warning, emergency stop.

The Flex G750DBR counterbalanced mobile crane also has a multifunctional display showing charge level, battery voltage and hours of operation.

Lift, lower, extend and retract of the boom are electric controlled. All movements are adjustable by the operator through a wireless remote control. Speed ​​and proportionality are managed via the potentiometer on the remote control.

It is a universal mobile crane with unlimited application possibilities. With the FLEX G750DBR mini crane, thanks to its 270° rotation and telescopic boom, components such as moulds, spare parts, semi-finished products and other loads can be placed on CNC machining centers, racks, assembly benches and any hard-to-access location.

Safety features :

Dynamic load limiter that prevents overloading and potential accidents. It continuously monitors the load being lifted or handled and automatically limits the operation if the load exceeds the predetermined safe limit.

A block valve is activated automatically in the event of a hydraulic hose rupture, preventing uncontrolled load descent.



The tiller handle is equipped with a speed selector that allows the speed of the vehicle to be adapted to different operating requirements. Two positions are available:

  • Slow mode: Limits the maximum speed to 1.5 km/h, ideal for precise manoeuvring in confined spaces and gentle handling of loads.
  • Standard speed: Allows a maximum speed of 3 km/h, suitable for travelling long distances in standard conditions

The FLEX G750DBR counterbalanced crane allows loads to be handled and lifted in full compliance with current regulations for the protection of operator safety.

Additional information

Trazione

Electric. Slow/fast speed
Altezza Max (mm)

3938
Colonna

Swivel 270°
Salita

Electric with adjustable and proportional speed
Portata Max (Kg)

750
Ingombro Frontale (mm)

990
Sbalzo Max (mm)

2400
Discesa

Electric with adjustable and proportional speed
Sfilo

Electric with adjustable and proportional speed

Reviews

There are no reviews yet.

Be the first to review “FLEX G750DBR MOBILE LIFTING SWIVEL CRANE”

Your email address will not be published. Required fields are marked *

Benefits
Product Brochure
Data Sheet
Video

PRECISE POSITIONING

The use of mini cranes, especially the ones equipped with a progressive speed control, lead to a better accuracy when positioning a load or a component that must be handled with care such as molds, engines,etc.

ERGONOMICS

The main goal of ergonomics is to develop and apply the man adaptation techniques to their work and efficient and safe ways in order to optimize the well-being and thus increasing productivity. The implementation of our mobile cranes helps our customers to achieve objective results by carrying out operations with the best ergonomics conditions and by using the most appropriate equipment.

VERSATILE AND FLEXIBLE

Unlike fixed cranes, mobile cranes can move to several plant areas. No licence required. Our cranes can get closer to the load even in presence of obstacles or perimeter protections. They can be equipped with several types of below the hook accessories.
The use of mini cranes, especially the ones equipped with a progressive speed control, lead to a better accuracy when positioning a load or a component that must be handled with care such as molds, engines, etc.

Download
Download

Optional and upgrades

TPG_500-Foldable-load-platform-mm-990x500-capacity-500-kg

TPG500 Foldable load platform mm 990×500 capacity 500 kg

battery-3

B100LIT24 Upgrade to LITHIUM battery 100A 24V

RCJ-Upgrade-to-radio-control-with-proportional-joystick

RCJ Upgrade to radio control with proportional joystick

hook

PLE Lifting eye bolts kit
